| Parameters | LH1.25 | LH1.5 | LH1.6 | LH1.8 | LH 2.0 | LH 2.5 | LH 3.0 | LH4.0 |
| Pixel Pitch(mm) | 1.25 | 1.538 | 1.667 | 1.839 | 2 | 2.5 | 3.076 | 4 |
| LEDconfiguration | SMD1010 | SMD1212 | SMD1515 | SMD2020 |
| Module size(mm) | 320*160*14 |
| Module resolution | 256*128 | 208*104 | 192*96 | 172*86 | 160*80 | 128*64 | 104*52 | 80*40 |
| Cabinet size(mm) | 640*480*50 |
| Cabinet resolution | 512*384 | 416*312 | 384*288 | 344*258 | 320*240 | 256*192 | 208*156 | 160*120 |
| Cabinet weight(kg) | 6 |
| Brightness(cd/m2) | 500-1000 |
| Max Power Consumption | 580(W/m2) | 450(W/m2) | 460(W/m2) | 420(W/m2) | 480(W/m2) |
| Avg Power Consumption | 193(W/m2) | 150(W/m2) | 193(W/m2) | 140W/m2) | 160(W/m2) |
| Refresh rate | 3840Hz | 1920Hz |
| IPRatingfFront/Rear) | IP31/IP30 |
FAQ:
Q1. What about LED Display MOQ?
A1. Any quantity is acceptable for your order. And the price is
negotiable for large quantity.
Q2. What about Longvision capacity?
A2.3000sqm per month.
8 modernized dust-free and static-free production lines,
6 new YAMAHA and PANASONIC high speed SMT machines,
2 large leadless reflow oven
250 skilled workers.
Q3. When will you make the delivery?
A3. 3-5 working days when we have LED module stock
10-15 days for the new production led finished screen according to
the size and quantities of your order.
Q4. How about the warranty time?
A4. Our standard is 2 years.
But you are willing to pay extra money for after sales and adopt
industry top quality material,we can accept 3-5 years warranty.
Q5. Do you provide any free spare parts in each order?
A5. Yes, a certain amount of spare parts will be provided for free,
spare parts including module, power cable,signal cable, LED
lamp, IC, mask, power supply, receiving card, etc.
Q6. What`s trade terms you accept?
A6. We accept EXW,CIF,CNF,DDP,DDU etc
