    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8

    Ask Lasest Price
    Model Number : TS series
    Brand Name : Longvision
    Supply Ability : 3000 Square Meter/Month
    Price : negotiable
    Certification : CE, ROHS, UL, FCC
    Payment Terms : T/T
    Delivery Time : 7-20 work days
    • Product Details
    • Company Profile

    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8

    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Advantages
    1. Transparent screen: front lighting transparent led screen adoptsmodular design, with high transparency, energy saving and environmental protection.
    2. can be taken Installation methods such as lifting and standing.
    3. There are several standard sizes of 1000x1000mm, 1000x500mm,500x500mm to fit different project sizes.
    Product Discription
    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Application
    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Glass Transparent Video Led Curtain Screen Panel For Concerts P2.8 P3.91 P7.8
    Specifications
    Mode
    TS2.84
    TS3.91
    TS7.81
    LEDs
    1R1G1B
    1R1G1B
    1R1G1B
    LED type
    SMD1415
    SMD1921
    SMD1921
    Pixel pitch
    W2.84mm*H6.25mm
    W3.91mm*H7.81mm
    W7.81mm*H7.81mm
    Unit size
    W1000mm*H500mm*D50mm
    Unit resolution
    352*80dots
    256*64 dots
    128*64 dots
    Resolution
    56320dots/㎡
    32768dots/㎡
    16384dots/㎡
    Transparency rate
    60%
    70%
    60%
    Brightness
    3000CD/㎡
    800/1500/4000/5000CD/㎡
    4000CD/㎡
    Cabinet Weight
    5KG
    5KG
    6KG
    Max consumption
    800W/㎡
    Adv consumption
    240W/㎡
    Refresh rate
    ≥3851Hz
    ≥3840Hz
    ≥1920Hz
    Working temperature
    ﹣10℃~51℃
    ﹣10℃~40℃
    ﹣10℃~40℃
    Life time
    ≥100,000 hours
    Input voltage
    AC170~240V
    Mode
    TS10.42
    TS15.625
    TS20
    LEDs
    1R1G1B
    1R1G1B
    1R1G1B
    LED type
    SMD1921
    SMD3535
    SMD3535
    Pixel pitch
    W10.42mm*H10.42mm
    W15.625mm*H15.625mm
    W10mm*H20mm
    Unit size
    W1000mm*H500mm*D50mm
    Unit resolution
    96*48dots
    64*32dots
    48*24dots
    Resolution
    9216dots/㎡
    4096dots/㎡
    2304dots/㎡
    Transparency rate
    65%
    75%
    85%
    Brightness
    4000CD/㎡
    4000CD/㎡
    4000CD/㎡
    Cabinet Weight
    6KG
    6KG
    6KG
    Max consumption
    700W/㎡
    600W/㎡
    500W/㎡
    Adv consumption
    200W/㎡
    180W/㎡
    150W/㎡
    Refresh rate
    ≥3851Hz
    ≥3840Hz
    ≥1920Hz
    Working temperature
    ﹣10℃~51℃
    ﹣10℃~40℃
    ﹣10℃~40℃
    Life time
    ≥100,000 hours
    Input voltage
    AC170~240V

    FAQ

    Q1. What about LED Display MOQ?
    A1. Any quantity is acceptable for your order. And the price is negotiable for large quantity.
    Q2. What about Longvision capacity?
    A2.3000sqm per month. 8 modernized dust-free and static-free production lines, 6 new YAMAHA and PANASONIC high speed SMT machines, 2 large leadless reflow oven,250 skilled workers.
    Q3. When will you make the delivery?
    A3. 3-5 working days when we have LED module stock,10-15 days for the new production led finished screen according to the size and quantities of your order.
    Q4. How about the warranty time?
    A4. Our standard is 2 years.But you are willing to pay extra money for after sales and adopt industry top quality material, we can accept 3-5 years warranty.
    Q5. Do you provide any free spare parts in each order?
    A5. Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
    Q6. What`s trade terms you accept?
    A6. We accept EXW,CIF,CNF,DDP,DDU etc
