    High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9

    Ask Lasest Price
    Model Number : DL Series
    Brand Name : Longvision
    Supply Ability : 3000 Square Meter per Month
    Price : negotiable
    Certification : CE, ROHS, UL, FCC
    Payment Terms : T/T
    Delivery Time : 7-20 work days
    • Product Details
    • Company Profile

    High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9


    Feature:

    ★ Front maintenance & Front Installation
    ★ High Refresh and High Grey Scale
    ★ Cabinet Dimension Ratio 16:9
    ★ Dual Backup Power & Data
    ★ Ultra Light and Ultra Thin
    ★ Cable Free Connection


    Specification


    Model
    FIW125
    FIW186
    FI2W
    LEDType
    SMD1515
    SMD1515
    SMD1515
    Physical Density (dot/m²)
    640000
    289050
    160000
    Module Size (W ×H ×D) mm
    320x160x17
    320x160x17
    320x160x17
    Module Resolution(W×H)
    256x128
    172x86
    128x64
    Cabinet Size (W ×H ×D) mm
    640x480x74
    640x480x74
    640x480x74
    Cabinet Material
    Die Casting Aluminum
    Die Casting Aluminum
    Die Casting Aluminum
    Scanning Mode
    1/64
    1/48
    1/32
    Cabinet Flatness(mm)
    ≤0.10
    ≤0.10
    ≤0.10
    Grey Scale (Bit)
    14
    14
    14
    Protection Level
    IP45
    IP45
    IP45
    Brightness(cd/㎡)
    500-900cd/㎡
    500-900cd/㎡
    500-900cd/㎡
    ColorTemperature
    3200-9300Kadjustable
    3200-9300Kadjustable
    3200-9300Kadjustable
    Brightness Uniformity
    ≥98%
    ≥98%
    ≥98%
    Horizontal/Vertical ViewAngle
    ≥140°/≥120°
    ≥140°/≥120°
    ≥140°/≥120°
    Contrast Ratio
    ≥5000:1
    ≥5000:1
    ≥5000:1
    Module Input Voltage DC
    5V
    5V
    5V
    Max Refresh Rate
    ≥3840Hz
    ≥3840Hz
    ≥3840Hz
    Input VoltageAC
    110-220V
    110-220V
    110-220V
    Cabinet Max Power Consumption
    ≤600W/m2
    ≤580W/m2
    ≤480W/m2
    Cabinet Aver.PowerConsumption
    ≤200W/m2
    ≤180W/m2
    ≤160W/m2
    Working Temperature
    20℃～+80℃
    20℃～+80℃
    20℃～+80℃
    Working Humidity
    10%～95%RH
    10%～95%RH
    10%～95%RH
    Installation/Service Method
    Front installation/Front service
    Front installation/Front service
    Front installation/Front service

    Product Discription

    High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9


    Application

    High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9High Definition Commercial Modular Led Digital Display Panels P1.9 P2.5 P2.9 P3.9


    FAQ

    Q1. What about LED Display MOQ?

    A1. Any quantity is acceptable for your order. And the price is negotiable for large quantity.
    Q2. What about Longvision capacity?
    A2.3000sqm per month. 8 modernized dust-free and static-free production lines, 6 new YAMAHA and PANASONIC high speed SMT machines, 2 large leadless reflow oven,250 skilled workers.
    Q3. When will you make the delivery?
    A3. 3-5 working days when we have LED module stock,10-15 days for the new production led finished screen according to the size and quantities of your order.
    Q4. How about the warranty time?
    A4. Our standard is 2 years.But you are willing to pay extra money for after sales and adopt industry top quality material, we can accept 3-5 years warranty.
    Q5. Do you provide any free spare parts in each order?
    A5. Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
    Q6. What`s trade terms you accept?
    A6. We accept EXW,CIF,CNF,DDP,DDU etc
